(I) unique combination design
1, our company set decades of manufacturing experience, with innovation and refinement of the concept, each function can be manufactured independently according to different requirements of assembly, can meet the general requirements of comfort air conditioning, hospital operation room and integrated circuit, strict clean room and clean process of air conditioning system.
2, the height and width of the unit can be flexibly chosen to meet the requirements of the field conditions on the overall size of the unit.
(two) reasonable structure, firm and durable, good thermal insulation performance
1, the use of reinforced aluminum alloy frame structure and connections, the whole unit of solid and tight, so that the unit force evenly, to ensure that the unit under high pressure without deformation.
2, the box panel is double wall structure, the use of 30-50mm thickness of fluorine free environmental protection polyurethane foam for thermal insulation materials, thermal conductivity is small, waterproof and heat insulation effect is good. At the same time, the interior design of the panel has a reinforced structure to make the unit more durable. The insulation protection between the panel and the frame completely eliminates the cold bridge phenomenon and has good sealing performance. The air leakage is small.
3. The whole structure is novel and unique. It has strong rigidity, light weight and convenient disassembly and assembly.
(three) excellent performance, excellent quality;
1, the surface cooler and heater are designed according to the ARI standard of American Association of air conditioning and refrigeration. The imported copper tube and aluminum foil heat exchanger production line equipment is adopted to produce the coil. The heat exchange efficiency of the coil is high, and the air resistance and water resistance are small. Condensate disc with special anti-corrosion treatment or stainless steel material. The heater can also use electric heating and steel tube winding aluminum sheet (steel sheet), steel aluminum (copper aluminum) composite pipe, steam and hot water heating mode.
2, the air returning machine adopts domestic advanced KF series of central air-conditioning special double inlet centrifugal fan or fan, the fan shaft and the impeller closely matched with dynamic balance correction, low noise and smooth operation, high efficiency, wide range of pressure head. Installation has 0 degrees, 90 degrees, 180 degrees, 270 degrees, a fan of low, medium and high pressure, which can meet the low head pressure head cooling system, constant temperature and humidity system and high pressure head cleaning system.
3, the use of high efficiency brand motors, unique design belt elastic adjustment mechanism, make it in clean and low temperature environment operation, effectively reduce motor energy consumption and extend its service life.
4. The blower and motor are installed on the spring damping seat, and the fan and the air outlet are soft connected, which can effectively separate and eliminate the vibration transmission.
5, according to the needs of the configuration can be dry steam humidification, high-pressure spray humidification, wet film humidification, ultrasonic humidifier, etc., high efficiency, energy saving significantly.
6, the unit is equipped with special design of the door, open, overhaul, maintenance convenience.
(four) each function paragraph name
The mixing section, primary filter section, water section, air return section, flow section and the heat recovery section, middle section, the filter section, a heating section, sterilization, blower, humidifying section, muffler section, air outlet section
Customers can assemble and use them in accordance with the air handling conditions and their own requirements.
